CH11449 Wellmate Tank Pump Mounting Bracket. Includes air valve extension.
Wellmate accessories ship FREE !
CH20515 WM Series (21-24" diameter) Quick Connect drain assembly(drain retaining clips but no adapters included). Fits QC style WM series tanks from WM-14WB to WM-35WB.
CH20765 WM Series (16" diameter) Quick Connect drain assembly(drain retaining clips but no adapters included). Fits QC style WM series tanks from WM-4 to WM12, WM-6LP & WM-10LP.
CH5484-1 WM Series (old style-threaded)1"NPT drain assembly. Fits original style WM series tanks from WM-4 to WM12, WM-6LP & WM-10LP. Material is schedule 80 pvc.
CH4233 WM Series (old style-threaded)1-1/4"NPT drain assembly. Fits original style WM series tanks from WM-14WB to WM-35WB. Material is schedule 80 pvc.
1" threaded outlet quick connect adapter replacement for connection to outlet of the Wellmate WM Series QC tanks.
CH20520 WM Quick Connect 1" MNPT Connector Noryl Kit
1-1/4" threaded outlet quick connect adapter replacement for connection to outlet of the Wellmate WM Series QC tanks.
CH20521 WM Quick Connect 1-1/4" MNPT Connector Noryl Kit
Make: Wellmate
Model: WM-6 air cell replacement kit
Product Number: CH3133-3
Details: Replacement bladder and installation accessories for a 20 gallon fiberglass pressure tank
Max. Operating Pressure: 125psig
Model: WM-9 air cell replacement kit
Product Number: CH3134-3
Details: Replacement bladder and installation accessories for a 30 gallon fiberglass pressure tank
Model: WM-12 air cell replacement kit
Product Number: CH3135-3
Details: Replacement bladder and installation accessories for a 40 gallon fiberglass pressure tank
Model: WM-14WB air cell replacement kit
Product Number: CH4466-1
Details: Replacement bladder and installation accessories for a 47 gallon fiberglass pressure tank
Model: WM-20WB air cell replacement kit
Product Number: CH4846-1
Details: Replacement bladder and installation accessories for a 60 gallon fiberglass pressure tank
Model: WM-25WB air cell replacement kit
Product Number: CH4467-1
Details: Replacement bladder and installation accessories for a 87 gallon fiberglass pressure tank
Model: WM-35WB air cell replacement kit
Product Number: CH4468-1
Details: Replacement bladder and installation accessories for a 119 gallon fiberglass pressure tank
Model: WM-6LP low profile air cell replacement kit
Product Number: CH12762-1
Details: Replacement bladder and installation accessories for a 20 gallon low profile fiberglass pressure tank
Model: WM10-LP low profile air cell replacement kit
Product Number: CH12763-1
Details: Replacement bladder and installation accessories for a 35 gallon low profile fiberglass pressure tank
Wellmate
CH20364 tank stand - fits 16" diameter WM-4, WM-6, WM-9 & WM-12 QC tanks.
Note: Pictures may not be of actual base and are intended for illustration purposes only.
CH20343 tank stand - fits 21-24" diameter WM-14WB, WM-20WB, WM-23WB & WM-25WB & WM-35WB QC tanks.
CH10795 Tank stand fits original type UT-30, UT-40, HP-7, HP-9, WM-4, WM-6, WM-9, WM-12, WM-6LP & WM-10LP.
CH10798 tank stand - fits original type UT-40SQ, UT-120, HP-8SQ, HP-26, WM-14WB, WM-20WB, WM-23WB, WM-25WB, WM-35WB tanks.
CH11577-2 tank stand - fits original type WM-14WB tank.
CH11606 tank stand - fits original type WM-6LP and WM-10LP tanks.
CH14743 tank stand height extenders - fits original type 16" diameter WM-4, WM-6, WM-9 & WM-12 tanks.
This CH10054 can be used to manually fill a UT Series tank with air pressure. It can be screwed into the UT top adapter 1/4" NPT.
To Go Back To The Precceding Page Use The Orange Back Button Above The Micronizer Picture
Back To Description Only
Micronizer
Part Number: CH3929-5
Inlet and Outlet: 1" MNPT
The Wellmate Micronizer installs in the pipe prior to the tank. It injects an adjustable timed amount of air into the water stream flowing to the tank. As the aerated water enters the tank, air escapes from the top of the water pushing the lighter gases out the top of the tank. This air escapes through the air volume control valve mounted in the top of the HP Series tanks. After the predetermined amount of aereated water enters the tank, the airs escape is closed (controlled by the air volume control valve). The pump continues to fill the tank with water compressing the air remaining in the tank until it reaches shut off pressure controlled by the pumps pressure switch. Now your water is odor free, pressurized and ready for your use.
Wellmate CH19426 Vacuum Breaker - 1/4IN Outside NPT Tank Mounting and 1/4" Inside NPT Inlet
1" inside or 1-1/4" outside connector pvc socket outlet quick connect adapter replacement for connection to outlet of the Wellmate UT & HP Series QC tanks.
CH20524 WM Quick Connect 1" MNPT Connector Noryl Kit
CH11068 Internal drain adapter to 1" pipe. Allows for installation of a 1" pipe to be extended above water level of UT or HP Series tank. Water outlet pipe when aerated above the water level releases undesirable gases out of the tank vent.
The CH20347 is a replacement for the top of the air volume control valve assembly. This HP top vent adapter is a quick connect type and fits the newer style tanks.
The CH19605 has a 1-1/4" glue outlet port. This UT tank top adapter is threaded and fits the original style tanks.
The CH14938 has a 1-1/4"NPT threaded outlet port. This UT tank top adapter is threaded and fits the original style tanks.
Use the CH5551 Air Volume Control Valve when you have an older style tank (threaded type). Be sure to discharge all air pressure then unscrew the valve assembly from the top of the tank Cut off the old valve from the end of the assembly. The new valve comes with 1/2NPT which can be installed using a pvc 1/2" female adapter glued onto the 1/2" pipe assembly.
HP-7 Air Volume Control Valve- QC (Quick Connect Type)
Wellmate Part: CH20287
Note: Installing this air volume control valve in the top of a Wellmate UT-30 will convert the tank to a Wellmate HP-7 Hydro-pneumatic Air/Water Tank. For air injection install a Wellmate micronizer inline between the pump and tank.
HP-8SQ Air Volume Control Valve- QC (Quick Connect Type)
Wellmate Part: CH20288
Note: Installing this air volume control valve in the top of a Wellmate UT-40SQ will convert the tank to a Wellmate HP-8SQ Hydro-pneumatic Air/Water Tank. For air injection install a Wellmate micronizer inline between the pump and tank.
HP-9 Air Volume Control Valve- QC (Quick Connect Type)
Wellmate Part: CH20289
Note: Installing this air volume control valve in the top of a Wellmate UT-40 will convert the tank to a Wellmate HP-9 Hydro-pneumatic Air/Water Tank. For air injection install a Wellmate micronizer inline between the pump and tank.
HP-18 Air Volume Control Valve- QC (Quick Connect Type)
Wellmate Part: CH20290
Note: Installing this air volume control valve in the top of a Wellmate UT-80 will convert the tank to a Wellmate HP-18 Hydro-pneumatic Air/Water Tank. For air injection install a Wellmate micronizer inline between the pump and tank.
HP-26 Air Volume Control Valve- QC (Quick Connect Type)
Wellmate Part: CH20291
Note: Installing this air volume control valve in the top of a Wellmate UT-120 will convert the tank to a Wellmate HP-26 Hydro-pneumatic Air/Water Tank. For air injection install a Wellmate micronizer inline between the pump and tank.
Drain assembly connection replacement for Wellmate UT and HP Series tanks.
Special male threads into tank with 1-1/4" female connection X 1-1/4" female slip connection.
Wellmate Part Number: CH10991-1
CH10798-1K tank stand - fits UT-80 & HP-18 tanks.
Wellmate Web Site - Tank Accessories
